Overview

  • Skulpt provides the bridge between Python and JavaScript. A “Python object” exists as a particular kind of JavaScript object.

  • One running instance of a Pytch program is represented by a Project; in the web-app, there is only one ‘live’ Project at a time.

  • A Scratch-like Sprite is represented by a user-written Python class derived from a Pytch-supplied base class; instances of the user’s classes represent the interacting elements of a Project.

  • A JavaScript-side Project has a collection of PytchActor objects, each representing such a Python class which has been registered with the Project.

  • Every PytchActor has at least one PytchActorInstance, each corresponding to a Python instance of the corresponding class; instances can be created and registered with the Project; all but the original instance can be de-registered from the Project.

  • Program execution happens via the Project maintaining a collection of Threads, organised into ThreadGroups; each Thread is ‘running on’ some PytchActorInstance.

  • ThreadGroups are launched in response to events; Threads are created to run Handlers; the user declares Handlers using Python decorator syntax.

  • Some events apply to all instances of an actor; some just to a particular instance. Some are exogenous; some endogenous.

  • Invoking a Handler consists of making a call to some Python method of some Sprite- or Stage-derived class, bound to some instance of that class.

  • A Thread can be ‘running’; or it can be ‘waiting’/’sleeping’ until some ‘wake’ condition holds; or it can have terminated.

  • Pytch system calls provide services requiring support from the Pytch runtime, such as the broadcast mechanism, which can launch new thread-groups.

  • Multi-threading is (sometimes implicitly) cooperative; execution proceeds in ‘frames’ (using that term as in animation); every frame, each running thread executes until it either finishes or cedes control back to the Pytch runtime.

  • When a thread cedes control, its continuation is captured as Skulpt suspension.

  • To achieve some implicit cooperation, ‘cede control’ calls are inserted by the Skulpt/Pytch compiler in ‘for’ and ‘while’ loops. Most system calls also implicitly cede control.

  • Cross-actor communication is done by broadcasting and receiving string messages.

  • All the above is decoupled from the browser, to allow easier testing; the handful of dependencies are configured as mocks; testing is then done in JavaScript (using node) on the behaviour of small Pytch programs.

  • For Scratch-like interactive use, there is a web-app which configures the Pytch dependencies to interact with the browser; it allows the user to enter code, save/load their work, or load Pytch-supplied examples.

  • The web-app runs threads and renders the current state of the live Project at a nominal 60fps; each Actor instance has an ‘appearance’, location, and size, and can be hidden or shown. The web-app supports sound, and approximate click- and collision-detection.
